Smart.UI MCP Server

01What this is and why you want it

smart-ui-mcp-server is a Model Context Protocol server that gives any MCP-aware coding assistant (Claude Code, Claude Desktop, Cursor, GitHub Copilot Chat in agent mode, Continue, Windsurf, Zed…) deep, accurate knowledge of the Smart.UI Web Components library.

It exposes:

• 110+ Smart.UI components with the full API surface - every property, method, event, CSS variable, and allowed-value enum, sourced from the official component metadata.
• The exact module import and theme stylesheet stack for any component - no more guessing whether the property is editing or editable, or which theme files to load and in what order.
• Demo browsing - the assistant can list and read every demo your repo ships, per framework (Web Components, React, Angular, Vue).
• Documentation browsing - the same for /documentation topics (overview.htm, api.htm, accessibility.htm, plus framework-specific guides for Angular, Blazor, React, Vue).
• A code generator that emits a complete runnable file for Web Components, React, Angular, Vue, and Blazor, with the right imports, theme stylesheet, attribute markup, and post-mount property assignments for complex options.

Why this beats freehand prompting

Without the MCP, an assistant has to guess Smart.UI API names from training data. With the MCP, the assistant queries the actual schema before writing code. Concretely:

• It writes editing (the real property name) instead of hallucinating editable.
• It emits the exact paths that exist in your node_modules - smart.default.css + fluent/light/smart.fluent.css for the theme stack, and a single smart.grid.js import that already bundles every sub-module - not a guess.
• It can crib a working pattern from demos/grid/grouping/ instead of inventing one.

0260-second quick start

1. Install Claude Code (skip if you already have it)
npm install -g @anthropic-ai/claude-code

2. Register the Smart.UI MCP server
claude mcp add smart-ui npx smart-ui-mcp-server

3. Open any project and ask:
claude
> Use the smart-ui MCP. Generate a Web Components page with a smart-grid
> bound to a 10-row JSON array of employees (id, name, position, salary),
> with sorting and paging enabled. Theme fluent.

You'll get a complete runnable index.html with the right tag, imports, and config.

03Installation

From npm (recommended)

global install
npm install -g smart-ui-mcp-server

or call directly with npx (no global install needed)
npx smart-ui-mcp-server

The package bundles a snapshot of the Smart.UI API metadata (110 components, ~4 MB unpacked) so it works zero-config straight after install. No live Smart.UI checkout is required for the core tools.

From a tarball

If you received smart-ui-mcp-server-1.0.0.tgz directly:

npm install -g ./smart-ui-mcp-server-1.0.0.tgz

From source

git clone <repo-url>
cd smart-ui-mcp-server
npm install
npm test          45 smoke tests should pass
npm start         run the server over stdio (for manual probing)

Requirements

• Node.js 18 or newer (uses ESM and the modern fs promises API).
• Any MCP-capable assistant. Each one has its own config format - see the next section.

04Connecting your assistant

The Smart.UI MCP server speaks MCP over stdio. Every assistant below uses the same underlying command (

npx smart-ui-mcp-server

Claude Code (CLI)

The cleanest path. From any directory:

To verify: claude mcp list. To remove later: claude mcp remove smart-ui.

Add it project-locally instead by passing --scope project, which writes to .mcp.json in the project root and is auto-picked-up by anyone who clones the repo.

Claude Desktop

Edit claude_desktop_config.json:

• macOS: ~/Library/Application Support/Claude/claude_desktop_config.json
• Windows: %APPDATA%\Claude\claude_desktop_config.json

{
  "mcpServers": {
    "smart-ui": {
      "command": "npx",
      "args": ["smart-ui-mcp-server"]
    }
  }
}

Restart Claude Desktop. The tools should appear under the 🔨 hammer icon in the message input.

VS Code - GitHub Copilot Chat (agent mode)

Create .vscode/mcp.json in your workspace root:

{
  "servers": {
    "smart-ui": {
      "type": "stdio",
      "command": "npx",
      "args": ["smart-ui-mcp-server"]
    }
  }
}

Open Copilot Chat, switch to agent mode, and ask a Smart.UI question. The tools appear automatically.

Cursor

Cursor uses ~/.cursor/mcp.json (or <workspace>/.cursor/mcp.json for project scope):

{
  "mcpServers": {
    "smart-ui": {
      "command": "npx",
      "args": ["smart-ui-mcp-server"]
    }
  }
}

Continue

Edit ~/.continue/config.json:

{
  "experimental": {
    "modelContextProtocolServers": [
      {
        "transport": {
          "type": "stdio",
          "command": "npx",
          "args": ["smart-ui-mcp-server"]
        }
      }
    ]
  }
}

Windsurf

Edit ~/.codeium/windsurf/mcp_config.json:

{
  "mcpServers": {
    "smart-ui": {
      "command": "npx",
      "args": ["smart-ui-mcp-server"]
    }
  }
}

Zed

Add to ~/.config/zed/settings.json:

{
  "context_servers": {
    "smart-ui": {
      "command": {
        "path": "npx",
        "args": ["smart-ui-mcp-server"]
      }
    }
  }
}

05Verifying the connection

After restarting your assistant, ask:

A working setup will respond with a list of 100+ smart-* tags. If it says “I don't have access to that information” or makes up tag names that don't start with smart-, the MCP isn't wired in - check your config file path and restart the assistant.

You can also test directly from a shell:

echo '{"jsonrpc":"2.0","id":1,"method":"tools/list"}' | npx smart-ui-mcp-server

(Press Ctrl+C after a second.) You should see a JSON response listing all 13 tools.

06The 13 tools at a glance

07How to refer to a component

Every Smart.UI component has three equivalent identifiers; the MCP accepts any of them in every tool call:

• bare slug - button, dropdownlist, ganttchart
• custom-element tag - smart-button, smart-drop-down-list, smart-gantt-chart
• class name - Button, DropDownList, GanttChart

All three resolve to the same component record. The generator always emits the canonical Smart.UI form in the output code - <smart-grid> for HTML / Vue, <Grid> for React / Blazor, and empre class="prettyprint"><smart-grid> with GridComponent for Angular.

08Worked tutorial - Grid (Web Components)

What happens under the hood

1. The assistant calls get_widget("grid"). It learns the tag is smart-grid, the class is Grid, the available feature modules include sort, filter, pager, edit, group, export, reorder, select, tree, and the shorthand attributes include sortable, filterable, pageable, editable, groupable, selectable, columnResize, columnReorder.
2. Because the prompt only asks to switch features on, the assistant picks the shorthand attributes (cleaner config) over the configurable object properties.
3. It calls get_required_scripts("grid", { theme: "fluent" }) and gets two stylesheet links - smart.default.css (base) plus fluent/light/smart.fluent.css (overlay) - and exactly one module URL: smart.grid.js. That single file already imports every sub-module (sort, filter, pager, edit, …); no extra script tags needed.
4. It calls generate_example with the merged options.

What you get

<!DOCTYPE html>
<html lang="en">
<head>
    <meta charset="UTF-8" />
    <title>Grid example</title>
    <!-- smart.default.css is the base; smart.fluent.css overlays it -->
    <link rel="stylesheet" type="text/css" href="../../../source/styles/smart.default.css" />
    <link rel="stylesheet" type="text/css" href="../../../source/styles/fluent/light/smart.fluent.css" />
    <!-- smart.grid.js already bundles sort/filter/pager/edit/group/… -->
    <script type="module" src="../../../source/modules/smart.grid.js"></script>
</head>
<body>
    <div id="grid"></div>
    <script type="module">
      window.addEventListener('load', () => {
        new Smart.Grid({
            dataSource: new Smart.DataAdapter({
                dataSource: [
                    { id: 1, name: 'Nancy Davolio', position: 'Sales Rep', salary: 60000 },
                    { id: 2, name: 'Andrew Fuller', position: 'VP Sales',   salary: 95000 },
                ],
                dataFields: [
                    'id: number',
                    'name: string',
                    'position: string',
                    'salary: number',
                ],
            }),
            sortable: true,
            filterable: true,
            pageable: true,
            columns: [
                { label: 'ID',       dataField: 'id' },
                { label: 'Name',     dataField: 'name' },
                { label: 'Position', dataField: 'position' },
                { label: 'Salary',   dataField: 'salary', cellsFormat: 'c0' },
            ],
            appendTo: '#grid',
        });
      });
    </script>
</body>
</html>

Theme application - always layer the overlay on the default base

<link rel="stylesheet" href="…/source/styles/smart.default.css" />                <!-- base -->
<link rel="stylesheet" href="…/source/styles/fluent/light/smart.fluent.css" />    <!-- overlay -->

Theme paths in the source repo are nested. Each non-default theme has its own subfolder under

source/styles/<theme>/

light/

dark/

source/styles/smart.default.css

source/styles/fluent/light/smart.fluent.css

source/styles/fluent/dark/smart.fluent-dark.css

source/styles/material/light/smart.material.css

source/styles/material/dark/smart.material-dark.css

source/styles/bootstrap/light/smart.bootstrap.css

source/styles/<theme>/light/smart.<theme>.css

get_required_scripts(..., { theme: 'fluent' })

dark: true

*-dark.css

The npm-packaged React and Angular distributions flatten the most common themes to the top level (so React's generated code uses

smart-webcomponents-react/source/styles/smart.fluent.css

smart-webcomponents

theme="fluent"

theme

One script tag per component - sub-modules are bundled

Smart.UI's top-level

smart.<component>.js

smart.grid.js

smart.grid.sort.js

smart.grid.filter.js

smart.grid.edit.js

smart.grid.pager.js

smart.grid.group.js

<script type="module">

bundledSubmodules

get_required_scripts

features

get_widget

<script>

Shorthand attributes vs full configuration

Smart Grid (and many other components) accepts two parallel ways of toggling behaviour. Prefer the shorthand attributes whenever you only need to switch a feature on or off. They produce cleaner, more declarative HTML.

Switch to the object-form property only when you need to configure how the feature behaves (filter mode, page size, batch-edit, multi-sort, etc.). The MCP surfaces the available shorthand attrs for each component via

get_widget

shorthandAttributes

sortable filterable

SMART_UI_SCRIPTS_PREFIX="/assets/smart-webcomponents/" npx smart-ui-mcp-server

prefix: "/assets/..."

generate_example

09Worked tutorial - Scheduler (React)

<Scheduler>

Behind the scenes

1. get_widget("scheduler") → tag smart-scheduler, class Scheduler.
2. get_widget_properties("scheduler", { nameFilter: "view" }) → confirms view, viewType, views, plus an enum of allowed view-type strings.
3. get_widget_types("scheduler") → returns the View enum (day, week, month, agenda, timelineDay…).
4. generate_example with framework: "react".

Result

import React from 'react';
import { createRoot } from 'react-dom/client';
// Theme stack: base first, overlay second.
import 'smart-webcomponents-react/source/styles/smart.default.css';
import 'smart-webcomponents-react/source/styles/smart.fluent.css';
import { Scheduler } from 'smart-webcomponents-react/scheduler';

function App() {
    return (
        <Scheduler
            view="week"
            views={['day', 'week', 'month']}
        />
    );
}

const root = createRoot(document.getElementById('root'));
root.render(<App />);

Grid-family components - use Smart.DataAdapter

For data-driven components (Grid, Chart, Scheduler, CardView, Kanban, GanttChart, PivotTable, QueryBuilder), the React import becomes

{ Smart, <Component> }

new Smart.DataAdapter({ dataSource, dataFields })

import { Smart, Grid } from 'smart-webcomponents-react/grid';

function App() {
    const dataSource = new Smart.DataAdapter({
        dataSource: [
            { id: 1, name: 'Alice', salary: 60000 },
            { id: 2, name: 'Bob',   salary: 75000 },
        ],
        dataFields: ['id: number', 'name: string', 'salary: number'],
    });

    return (
        <Grid
            dataSource={dataSource}
            sortable
            filterable
            pageable
            columns={[
                { label: 'ID',     dataField: 'id' },
                { label: 'Name',   dataField: 'name' },
                { label: 'Salary', dataField: 'salary', cellsFormat: 'c0' },
            ]}
        />
    );
}

get_widget_properties("scheduler", { nameFilter: "data" })

dataSource

get_demo_code("scheduler", "recurring")

10Worked tutorial - Chart with annotations (Angular)

The MCP path

1. get_widget("chart") → features include annotations.
2. get_required_scripts("chart", { features: ["annotations"], theme: "fluent" }) adds smart.chart.annotations.js to the module list.
3. get_widget_properties("chart", { nameFilter: "annotation" }) → confirms the annotations property and its shape.
4. generate_example with framework: "angular".

import { Component, ViewChild, AfterViewInit } from '@angular/core';
import { ChartComponent, ChartModule } from '@smart-webcomponents-angular/chart';

// angular.json -> "styles": [
//   "./node_modules/@smart-webcomponents-angular/chart/styles/smart.base.css",
//   "./node_modules/@smart-webcomponents-angular/chart/styles/smart.chart.css",
//   "./node_modules/@smart-webcomponents-angular/chart/styles/smart.common.css",
//   "./node_modules/@smart-webcomponents-angular/chart/styles/smart.fluent.css"  // theme overlay
// ]

@Component({
    selector: 'app-root',
    standalone: true,
    imports: [ChartModule],
    template: `<smart-chart #chart></smart-chart>`,
})
export class AppComponent implements AfterViewInit {
    @ViewChild('chart', { read: ChartComponent, static: false })
    chart!: ChartComponent;

    ngAfterViewInit(): void {
        this.chart.caption = 'Monthly Sales';
        this.chart.seriesGroups = [{
            type: 'line',
            series: [{ dataField: 'sales', displayText: 'Sales' }],
        }];
        this.chart.annotations = [{
            type: 'line',
            xAxis:    { value: 0  }, yAxis:    { value: 5000 },
            xAxisEnd: { value: 11 }, yAxisEnd: { value: 5000 },
            lineColor: '#d33', lineWidth: 2,
        }];
    }
}

11Worked tutorial - Tree + context menu (composition)

This is the most ambitious type of prompt - the assistant composes two components.

smart-tree

smart-menu

The MCP path

1. get_widget("tree") - confirms smart-tree with allowDrag, filterable, selectionMode.
2. get_widget("menu") - confirms smart-menu with mode="dropDown" and a select event.
3. get_widget_events("tree", { nameFilter: "context" }) - finds an event the assistant can use to position the menu, or falls back to the native contextmenu DOM event.
4. list_demos("tree") - looks for any shipped right-click pattern; if one exists, get_demo_code reads it.
5. generate_example is called twice - once for tree, once for menu - and the assistant manually composes them in one HTML file.

The output combines the two generated stubs with a

contextmenu

12Prompt patterns - a cheat sheet

The MCP works best when your prompt includes:

1. An explicit “Use the smart-ui MCP” - primes the assistant to call the tools instead of guessing.
2. A target framework - webcomponents, react, angular, vue, or blazor.
3. A theme name if you care - default, fluent, material, bootstrap, strata, tabula.
4. The features you want by name - e.g. “sorting, paging, filtering, row grouping”. The assistant will resolve these to the right feature modules via get_required_scripts.

Templates

Generate from scratch

Adapt a shipped demo

API exploration

Migration / fix

13Configuration reference

All env vars are optional.

Setting env vars per-client

Most MCP clients pass through env vars from your shell. To set them per-server (instead of globally), use the

env

{
  "mcpServers": {
    "smart-ui": {
      "command": "npx",
      "args": ["smart-ui-mcp-server"],
      "env": {
        "SMART_UI_REPO_ROOT": "/Users/me/code/smart-ui-repo",
        "SMART_UI_SCRIPTS_PREFIX": "/assets/smart/"
      }
    }
  }
}

14Local development & contributing

git clone <repo>
cd smart-ui-mcp-server
npm install

rebuild the bundled snapshot from a Smart.UI checkout
SMART_UI_REPO_ROOT=/path/to/Team npm run build-data

run the 45-test smoke suite
SMART_UI_REPO_ROOT=/path/to/Team npm test

run the server interactively (for hand-rolled JSON-RPC probing)
npm start

Adding a new tool

1. Implement the logic in src/<area>.js (or a new module).
2. Register it in src/server.js with server.registerTool(...). Use Zod to declare the input schema.
3. Add a smoke test in test/smoke.js.
4. Update README.md and this tutorial's tools table.

Updating the bundled API metadata

Whenever Smart.UI ships new components or new properties:

SMART_UI_REPO_ROOT=/path/to/Team npm run build-data

This refreshes

data/api/*.json

data/features.json

data/themes.json

data/widget-scripts.json

data/snapshot.json

15Troubleshooting

“Tool not found” / the assistant doesn't see Smart.UI

• Restart the assistant after editing the MCP config.
• Confirm the config file path is the one your assistant actually reads (Claude Desktop on Windows is

  %APPDATA%\Claude\

  , not

  %LOCALAPPDATA%

  ).
• Run

  npx smart-ui-mcp-server

  from a terminal - if it starts without errors, the binary is fine and the issue is in your client config.

“Smart.UI API metadata not found”

The bundled snapshot lives in

data/api/

npm install

npm uninstall -g smart-ui-mcp-server
npm install -g smart-ui-mcp-server

If you're running from source, run

npm run build-data

Generated examples reference modules that don't exist on disk

The default

SMART_UI_SCRIPTS_PREFIX

../../../source/

<repo>/demos/<widget>/<example>/index.html

<repo>/source/

list_demos

returns an empty array

The demos browser only works against a local Smart.UI checkout. Set

SMART_UI_REPO_ROOT

demos/

react/demos/

smart-angular/demos/

vue/vue-3/demos/

The assistant emits the wrong tag name

If the generated code uses an unfamiliar prefix or a tag that doesn't start with

smart-

get_widget

tag

“Unknown widget” errors

Smart.UI uses kebab-case multi-word tags. If you call

getWidget("dropdown-list")

"DropDownList"

"dropdownllist"

list_widgets({ filter: "drop" })

16FAQ

Does this require an Anthropic API key / Claude subscription?

No. The MCP server itself is plain Node.js with no API calls. It only provides knowledge to whatever assistant you've connected - that assistant provides its own model.

Does it work offline?

Yes. After

npm install

Can I use it with my own private Smart.UI fork?

Yes. Set

SMART_UI_REPO_ROOT

npm run build-data

SMART_UI_REACT_PACKAGE

Does it cover Smart.UI for Blazor too?

Yes -

generate_example

framework: "blazor"

@using Smart.Blazor

<Button Value="…" />

Can I add my own custom-component metadata?

Yes. Drop additional

<slug>.json

SMART_UI_REPO_ROOT

npm run build-data

How big is the bundled snapshot?

~4 MB unpacked, ~720 KB packed. The bulk is the per-component API JSON.

How do I report a bug?

Open an issue at github.com/HTMLElements/smart-webcomponents/issues with: the prompt you used, the tool call(s) the assistant made, the actual vs expected output, and your assistant + MCP server versions.
